DITEC PWR 230V COMPLETE MOTOR KIT FOR SWING GATE 5M PER LEAF PWR50AC ML352
  • DITEC PWR 230V COMPLETE MOTOR KIT FOR SWING GATE 5M PER LEAF PWR50AC ML352

DITEC PWR 230V COMPLETE MOTOR KIT FOR SWING GATE 5M PER LEAF PWR50AC ML352

PWR50AC-ML352

DITEC PWR 230V COMPLETE MOTOR KIT FOR SWING GATE 5M PER LEAF PWR50AC ML352

KIT CONSISTS OF:

2 PWR50AC SWING GATE ACTUATOR

1 LCA70 CONTROL PANEL WITH BUILT-IN RADIO RECEIVER

1 PAIR OF LIN2 PHOTOCELLS

1 ROLLING CODE 2CH REMOTE CONTROL (1 X ZEN2)

1 FLM 230V FLASHING LIGHT

1 AXK5M STEEL KEY SWITCH

€878.00
VAT included
Quantity
Out-of-Stock

  Security policies

Secure site in SSL certification for the security of your data

  Shipping policies

Shipping in 24/48 hours after payment

  Return policy

Maximum times for returns 14 days, the goods must return as shipped by us,

Description

Technical Specifications

DITEC 230V PWR50AC MOTOR

5M SWING GATE

REVERSIBLE IRREVERSIBLE FOR INTENSE USE

Type: Irreversible/Reversible

Travel control (limit switch)

Mechanical stop (opening)

Power supply: 230V ~ / 50Hz

Maximum current draw: 1.1A

Power consumption: 250W

Maximum thrust: 6000N

Maximum stroke: 500mm

Opening time: 32s / 90°

Intermittent operation: 200 cycles/day [max] - 30 consecutive cycles at 20°C

Lifespan: 150,000 to 450,000

cycles depending on the conditions shown in table 3.1 (see product durability graphs)

Operating temperature: -20°C / +55°C (-35°C + 55°C with NIO active)

Protection rating IP44

Dimensions (mm) 1044x100x124h

Actuator weight (kg) 10.5

LCA70 control panel

Product Details
PWR50AC-ML352
Attachments
Download
Technical manual

Ditec LCA70

Download (1.38MB)
Technical manual

Ditec PWR50AC

Download (1.62MB)
